| Installation Type (Cooking) |
Wall-mounted |
| Ukupna potrošnja energije |
129 W |
| Vrsta aspiratora |
Standardni |
| Kontrole |
Kontrola preko mehaničkog slajdera |
| Display / LED Colour |
Red |
| Broj nivoa snage |
3 |
| Vrsta osvetljenja |
LED Illumination® |
| Snaga sijalice |
4 W |
| Broj sijalica |
1 |
| Control Panel Design |
Flat Panel |
| Karbonski filteri |
Opcionalno |
| Spare Parts – No. of Necessary Charcoal Filters |
1 |
| Control Panel Type |
Metal |
| Color – Chimney |
Silver |
| Material – Body |
Inox |
| Material – Chimney |
Painted Metal |
| Glass Visor |
Yes |
| Rating Label (Hood) |
Standard |
| Packaging Label Pls. Specify (Hood) |
Standard |
| Boja |
Nerđajući čelik |
| Broj filtera za masnoću |
1 |
| Dizajn filtera |
Metalni rešetkasti filter |
| Number of Motors |
1 |
| Maksimalni kapacitet ventilacije |
295 m³/h |
| Noise levels (sound power) based on dB(A) re 1 pW according to DIN/EN 60704-3 standard |
56 – 64 – 69 |
| Maksimalni nivo buke ventilacije |
69 dBA |
| Production Location (Hood) |
Turkey |
| Fitting Kit (screws) |
Yes |
| Širina |
60 cm |
| Supplier |
Faber |
| Klasa efikasnosti dinamike fluida (motor) |
E |
| Klasa efikasnosti osvetljenja |
E |
| Klasa efikasnosti filtriranja masnoće |
G |
| Prosečna godišnja potrošnja električne energije |
64.3 kWh |
| Declared Sound Power According to Energy Regulation (EP) |
69 dBA |
| Annual Energy Consumption(kWh/a) |
64.3 |
| Time increase factor |
1.7 |
| Fluid Dynamic Efficiency (EP) |
8.1 |
| Energy Efficiency Index |
89.3 |
| Measured air flow rate at best efficiency point (M3/h) |
149.0 |
| Measured air pressure at best efficiency point(Pa) |
193.0 |
| Measured electric power input at best efficiency point(W) |
99.0 |
| Maximum air flow (M3/h) |
295.0 |
| Nominal power of the lighting system(W) |
4.0 |
| Average illumination of the lighting system on the cooking surface(lux) |
45.0 |
| Sound power level(dB) |
69 |
| Energy efficiency class for hoods |
D |
| Fluid Dynamic Efficiency Class |
E |
| Lighting Efficiency (EP) |
11.0 |
| Lighting Efficiency Class (EP) |
E |
| Grease Filtering Efficiency (EP) |
40.0 |
| Sound power level (dB) (min. and max. setting) |
56-69 |
| Air flow (m³/h) (min. and max. setting) |
135-295 |
| Minimalni kapacitet ventilacije |
135 m³/h |
| Minimalni nivo buke ventilacije |
56 dBA |
| Model Identifier for EPREL (EP) |
Marketing Code + SKU number |
| Stacking Level (Cooking) |
4 |
| Platform Name (Hood) |
Standard |
| Ventilation Capacities according to IN/EN 61591 standard (m3/h) |
135 – 200 – 295 |
